Signature Pad
YF0503 Signature Pad
Technical Specifications
| Category | Parameter | Value |
|---|---|---|
| Display | ||
| Panel Size | 5-inch | |
| LCD Type | TFT LCD | |
| Display Resolution | 800×480 Pixels | |
| Active Area | 108×64.8mm | |
| Contrast Ratio | 800:1 | |
| Brightness | 250 cd/m² | |
| Response Time | 16ms | |
| View Angle | 70°/70°/60°/60° (Typ.) (CR≥10) | |
| Digital Pen & Touch | ||
| Pen Technology | Battery-free electromagnetic | |
| Coordinate Resolution | 2540 LPI | |
| Pressure Level | 2048 | |
| Accuracy | ±0.5mm (center); ±3mm (corner) | |
| Sensing Height | 10mm | |
| Report Rate | 233 PPS | |
| Digital Pen | YP057S | |
| Pen Storage | 2 | |
| Power & Connectivity | ||
| Power Input | USB 5V/1A | |
| Power Consumption | 5W | |
| Interface | USB | |
| Connectivity Security | USB cable locking system | |
| Cable Length | 2 meter | |
| Security & Software | ||
| Security | Kensington Security Lock Slot | |
| Encryption | AES, RSA | |
| Development Environments | C++, .Net, Java SDK/API available for developer | |
| OS Compatible | Windows 7 or later, Android | |
| General | ||
| Color | Black or Customizable colors | |
| Dimension | 174 × 168 × 18mm | |
| Net Weight | 270g | |
| Working Temperature & Humidity | 0 - +40°C, 20-80% | |
| Storage Temperature & Humidity | -20°C ~ 60°C, 10-90% |
